1-12
IM 04P03B01-01E
For the procedure to set the functions, see section 1.6, “Function Setup Guide.”
Periodic Printout
Values such as the measured values are printed at a determined interval. The contents
of the printout vary between the pen model and dot model.
Printout cannot be performed at the following chart speeds.
Pen model: 1800 mm/h or higher; Dot model: 120 mm/h or higher
Time tick cancel mark
Offset compensation mark
Prints the letter “d” for channels set to
delta computation.
Alarm
Time tick
Unit
Measured
value
Channel No.
or tag
Date
Time
Channel data
Scale
Recording color
Chart speed
Mar.31.2006!
15:50*
TAG-001 1.000V
2 -1.000V
3 H-2.1050UNIT03
4 d 2.000V
0.000 2.000
TAG-001 V
RED
50mm/h_
The font used in the figure differs from that of the actual printout. The printout positions may
also differ from those of the actual printout.
• Printout Contents
• Date/Time: The date/time when the periodic printout was executed.
• Time ticks: Marks that indicate the first pen position of the date/time on the
chart paper. If the time tick is not printed in the correct position, the
pen model prints a time tick cancel mark (!), and the dot model does
not print the time tick.
• Offset compensation mark: When pen offset is being executed on the pen model,
asterisks (∗) are printed.
• Channel data: Prints the channel numbers or tags, measured values
(instantaneous values), and units.
• Alarm status: Prints the alarm that is occurring. Prints the letter “d” on channels
set to delta computation. If multiple alarms are occurring, the alarm
with the highest precedence is printed.
Alarm printout precedence: (Higher) H, L, h, and l (lower)
• Scale: Prints the leftmost and rightmost values of the recording span and
the channel number or tag for channels that have scale printout
specified. The scale is printed for one channel at each periodic
printout. The channel whose scale is printed changes in ascending
order. The scale of channels that are being zone recorded is printed
within the recording range of the zone for 40 mm or greater.
• Recording color (pen model): Prints the recording colors of channels that have
scale printout and recording color printout specified.
• Chart speed: The chart speed can be printed.
• For the measured values and alarm status, you can select whether to print them for
each channel. For the scale and recording color (pen model), you can select
whether to print them.
• Interval (for details, see appendix 1)
The printout interval can be set by specifying the value or set automatically in sync
with the chart speed.
• Turning ON/OFF the Periodic Printout
Periodic printout can be turn ON/OFF. By default, periodic printout is enabled with the
interval synchronized to the chart speed.
1.3 Recording
To Next Page
