1-14
IM 04P03B01-01E
For the procedure to set the functions, see section 1.6, “Function Setup Guide.”
Recording Start Printout
Printout cannot be performed at the following chart speeds.
Pen model: 1800 mm/h or higher; Dot model: 120 mm/h or higher
When recording is started, the time tick (dot model), the time, and the chart speed can
be printed. An asterisk (∗) shows there are messages that cannot be printed.
• The recording start printout can be enabled or disabled. By default, the recording start
printout is disabled.
• The time printout format can be selected.
Printout/Display Format of the Date.
The printout/display format of the date can be selected from the list below.
Selectable Type Printout Format Display Format Notes
Settings Example Example
Year/Month/Day 2006/03/31 06 03 31 Default value
Month/Day/Year 03/31/2006 03 31 06
Day/Month/Year 31/03/2006 31 03 06
Day.Month.Year 31.03.2006 31 03 06
Month.Day.Year Mar.31.2006 03 31 06
*1 These do not apply for the date printout format for message printouts that include measured
values (/BT1 option). Specify that in the message format.
Printout Format of the Time
The printout format of the time can be selected from the list below.
Selectable Type Printout Format Notes
Settings Example
Hour:Minute 10:00 Default value
Hour:Minute:Second 10:00:00
Month/Day Hour:Minute 03/31 10:00
Month/Day Hour:Minute:Second 03/31 10:00:00
Year/Month/Day Hour:Minute:Second 2006/03/31 10:00:00
*1: The year/month/day format varies depending on the printout/display format of the date.
*2: Can be set to the alarm printout, message printout, recording start printout, and new chart
speed printout.
*3 These do not apply for the date printout format for message printouts that include measured
values (/BT1 option). Specify that in the message format.
<Related Topics> Setting the printout/display format of the date: Section 4.14
Setting the printout format of the time: Section 4.16
1.3 Recording
To Next Page
