Storing and Recalling Data and Saving the Stored Data
• Setting the Store Reservation Time
(This operation is possible when the store mode is set to Real Time in section 8.1)
4. Press the Mode soft key to display the Mode menu.
5. Press the Real Time soft key to select the real-time mode. The store reservation
time menu appears.
6. Press the Real Time Control soft key to display the Real Time Control dialog
box.
7. Press the cursor keys to select one of the reservation year, month, date, hour,
minute, and second boxes for specifying when the storage operation will start
(Store Start).
8. Press SET to display the entry box.
9. Press the cursor keys to set the year, month, date, hour, minute, or second that
you selected in step 7.
10. Press SET or ESC to close the box.
11. Repeat steps 7 to 10 to set the year, month, date, hour, minute, and second.
12. Press the cursor keys to select one of the reservation year, month, date, hour,
minute, and second boxes for specifying when the storage operation will end
(Store End).
13. Repeat steps 8 to 11 to set the year, month, date, hour, minute, and second.
• Turning ON/OFF the Alert Indication for Internal Memory Initialization
1. Press SHIFT+STORE(STORE SET) to display the Store Set menu.
2. Press the Init Memory Alert Msg soft key to select ON or OFF.
8.3 Setting the Store Count, Store Interval, Store Reservation Time, and Alert Indication of Internal Memory
Initialization

YOKOGAWA wt3000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Input Elements	Up to 4 elements
Harmonic Measurement	Up to 500th order
Interfaces	USB, Ethernet, RS-232
Sampling Rate	2 MS/s
Voltage Range	1.5 V to 1000 V
Display	8.4-inch LCD
