Symbologies 11 - 5

Codabar (NW - 7)

Codabar 7 07h Enable

11-57

Set Lengths for Codabar 24, 25 18h, 19h 4 to 55

11-58

CLSI Editing 54 36h Disable

11-59

NOTIS Editing 55 37h Disable

11-59

Codabar Upper or Lower Case Start/

Stop Characters Detection

855 F2h 57h Upper Case

11-60

MSI

MSI 11 0Bh Disable

11-61

Set Length(s) for MSI 30, 31 1Eh, 1Fh 4 to 55

11-62

MSI Check Digits 50 32h One

11-64

Transmit MSI Check Digit 46 2Eh Disable

11-64

MSI Check Digit Algorithm 51 33h Mod 10/Mod 10

11-65

Chinese 2 of 5

Chinese 2 of 5 408 F0h 98h Disable

11-66

Matrix 2 of 5

Matrix 2 of 5 618 F1h 6Ah Disable

11-67

Matrix 2 of 5 Lengths 619

620

F1h 6Bh

F1h 6Ch

4 to 55

11-67

Matrix 2 of 5 Check Digit 622 F1h 6Eh Disable

11-69

Transmit Matrix 2 of 5 Check Digit 623 F1h 6Fh Disable

11-69

Korean 3 of 5

Korean 3 of 5 581 F1h 45h Disable

11-70

Inverse 1D

586 F1h 4Ah Regular

11-71

GS1 DataBar

GS1 DataBar-14 338 F0h 52h Enable

11-72

GS1 DataBar Limited 339 F0h 53h Enable

11-72

GS1 DataBar Expanded 340 F0h 54h Enable

11-73

Convert GS1 DataBar to UPC/EAN 397 F0h 8Dh Disable

11-73

GS1 DataBar Limited Security Level 728 F1h D8h Level 3

11-74

Table 11-1 Symbology Parameter Defaults (Continued)

Parameter

Number

SSI Number Default

Page

Number

Other manuals for Zebra DS3608

Quick Start Guide2 pages

User Guide2 pages

Questions and Answers:

Need help?

Do you have a question about the Zebra DS3608 and is the answer not in the manual?

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070
