Zebra DS3608 Product Reference Guide

11 - 6 DS3608 Digital Scanner Product Reference Guide
Composite
Composite CC-C 341 F0h 55h Disable 11-75
Composite CC-A/B 342 F0h 56h Disable 11-75
Composite TLC-39 371 F0h 73h Disable 11-76
UPC Composite Mode 344 F0h 58h UPC Never Linked 11-76
Composite Beep Mode 398 F0h 8Eh Beep As Each Code
Type is Decoded
11-77
GS1-128 Emulation Mode for UCC/EAN
Composite Codes
427 F0h ABh Disable 11-77
2D Symbologies
PDF417 15 0Fh Enable 11-78
MicroPDF417 227 E3h Disable 11-78
Code 128 Emulation 123 7Bh Disable 11-79
Data Matrix 292 F0h 24h Enable 11-80
GS1 Data Matrix 1336 F8h 05h 38h Disable 11-80
Data Matrix Inverse 588 F1h 4Ch Inverse Autodetect 11-81
Maxicode 294 F0h 26h Disable 11-81
QR Code 293 F0h 25h Enable 11-82
GS1 QR 1343 F8h 05h 3Fh Disable 11-82
MicroQR 573 F1h 3Dh Enable 11-83
Aztec 574 F1h 3Eh Enable 11-83
Aztec Inverse 589 F1h 4Dh Inverse Autodetect 11-84
Han Xin 1167 F8h 04h 8Fh Disable 11-84
Han Xin Inverse 1168 F8h 04h 90h Regular 11-85
Postal Codes
US Postnet 89 59h Disable 11-86
US Planet 90 5Ah Disable 11-86
Transmit US Postal Check Digit 95 5Fh Enable 11-87
UK Postal 91 5Bh Disable 11-87
Transmit UK Postal Check Digit 96 60h Enable 11-88
Japan Postal 290 F0h 22h Disable 11-88
Table 11-1 Symbology Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
