Zebra EC50 Product Reference Guide

Accessories
141
3.5 mm Audio Adapter
The 3.5 mm Audio Adapter connects a wired headset with a collared 3.5 mm plug. If using the 3.5 mm
Audio Adapter with a mono headset (for example, HS2100), then audio only plays in the left channel. To
combine the channels when playing audio, go to Settings > Accessibility and select Mono audio.
1. Connect the USB-C plug of the 3.5 mm Audio Adapter to the USB connector on the bottom of the
device.
2. Connect the 3.5 mm connector plug of the headset into the 3.5 mm Audio Adapter.
3. Use the clip to secure the adapter to clothing.
1 3.5 mm wired headset
2 Clip
3 3.5 mm audio adapter
2
3
1

Zebra EC50 Specifications

General

Suitable for	Barcode reader battery
Network ready	Yes
Power source type	DC
Brand compatibility	Zebra
Compatible products	EC50/EC55
Number of batteries supported	1
Compatible battery technologies	-
Product color	Black
Housing material	Plastic
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85044055
