Data Capture
72
Pairing the Bluetooth Ring Scanner
To connect the RS507/RS507X, RS5100, or RS6000 Bluetooth Ring Scanner to the device, use one of the
following methods:
• Near Field Communication (NFC) (RS5100 and RS6000 only)
• Simple Serial Interface (SSI)
• Bluetooth Human Interface Device (HID) Mode
NOTE: When establishing a connection, a pairing confirmation prompt may appear on devices without a
Mobility DNA Enterprise License.
Pairing Using Near Field Communication
The device provides the ability to pair the RS5100 or RS6000 using NFC.
NOTE: RS5100 and RS6000 Only.
To pair using NFC:
1. Ensure that the RS5100 or RS6000 is in SSI mode. Refer to the RS5100 or RS6000 User Guide for
more information.
2. Ensure that NFC is enabled on the device.
3. Align the NFC icon on the RS6000 with the NFC antenna on the device.
The RS5100 or RS6000 Status LED blinks blue indicating that the RS5100 or RS6000 is attempting to
establish connection with the device. When connection is established, the Status LED turns off and the
RS5100 or RS6000 emits a single string of low/high beeps.
A notification appears on the device screen and the icon appears in the Status bar.
1 NFC antenna
