Trigger Handle
The Trigger Handle adds a gun-style handle with a scanning trigger to the device. It increases comfort
when using the device in scan-intensive applications for extended periods of time.
Figure 27 Trigger Handle
Inserting the Device into the Trigger Handle
To install the device onto the Trigger handle:
1. Align and insert the top of the device into the front of the Trigger Handle.
1 Release tabs
2 Trigger
1
2
