Zebra EC50 Product Reference Guide

Accessories
154
Rack Mount Installation
NOTE: Use screws provided with rack system. Refer to rack user documentation for instructions.
1. Secure mounting brackets to both sides of top tray with four M5 screws (two on each side).
• For 5-Slot cradles, position the flange for horizontal installation.
• For 4-Slot Battery Chargers, position the flange for 25° installation.
CAUTION: Install mounting bracket with 5-Slot cradle at a maximum height of four feet from ground.
Install mounting bracket with 4-Slot Battery Charger at a maximum height of three feet from ground.
1Flange
2 Fifth screw hole
1 Top screw hole
2 Flange
2
1
1
2

Zebra EC50 Specifications

General

Suitable for	Barcode reader battery
Network ready	Yes
Power source type	DC
Brand compatibility	Zebra
Compatible products	EC50/EC55
Number of batteries supported	1
Compatible battery technologies	-
Product color	Black
Housing material	Plastic
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85044055
