Zebra EC50 Product Reference Guide

Accessories
156
4.
Place the brackets on the screws.
5. Secure the top screws.
6. Install bottom screws and tighten screws.
7. Route cables and connect to power source.
CAUTION: Installer should ensure that all building codes are followed when connecting the power supplies
to an AC power source.
While installing the brackets, power supplies and cables:
• Use tie wraps to secure cables to the bracket and rails.
• Coil cables wherever possible.
• Route power cables along the rails.
• Route inter-cradle cables to the side rails and then from the rails to the bracket.
14 “

Zebra EC50 Specifications

General

Suitable for	Barcode reader battery
Network ready	Yes
Power source type	DC
Brand compatibility	Zebra
Compatible products	EC50/EC55
Number of batteries supported	1
Compatible battery technologies	-
Product color	Black
Housing material	Plastic
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85044055
