Zebra MC67 Integrator Guide

A - 4 MC67 Integrator Guide
Data Capture Specifications
Options MC67NA Base Model:
2D SE4710 imager and 8 MP camera
2D SE4710 imager
MC67NA :
2D SE4500-SR imager and 8 MP camera
2D SE4500-SR imager
2D SE4500-DL imager and 8 MP camera
2D SE4500-DL imager
2D SE4500 DPM/HD and 8 MP camera
MC67ND :
2D SE4500-SR imager and 8 MP camera
2D SE4500-SR imager
2D SE4500-DL imager and 8 MP camera
2D SE4500-DL imager
2D SE4500 DPM/HD and 8 MP camera
Camera Specifications
Resolution 8 Mega pixel
Voice and Audio
VoWWAN; VoWLAN; PTT, VoIP-ready; high-quality speakerphone; wireless (Bluetooth) headset support; PTT
headset support; headset/speakerphone modes
2D Imager Engine (SE4500-SR) Specifications
Field of View Horizontal - 39.6°
Vertical - 25.7°
Optical Resolution WVGA 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 19 cm (7.5 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Table A-1 MC67 Technical Specifications (Continued)
Item Description

Zebra MC67 Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	-
Flash memory	2 GB
Internal memory	0.512 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	Instruments OMAP
Processor frequency	0.8 GHz
Processor manufacturer	Texas Instruments
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3600 mAh
Data network	4G, HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Keyboard layout	QWERTY
Operating system installed	Windows Mobile 6.5

Weight and Dimensions

Depth	33.5 mm
Width	77 mm
Height	162.2 mm
Weight	385 g
