Zebra MC67

Technical Specifications A - 5
2D Imager Engine (SE4500-DL) Specifications
Field of View Horizontal - 39.2°
Vertical - 25.4°
Optical Resolution WVGA 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
2D Imager Engine (SE4500-DPM) Specifications
Field of View Horizontal - 39.2°
Vertical - 25.4°
Optical Resolution WVGA 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Table A-1 MC67 Technical Specifications (Continued)
Item Description
