Cradle Installation
Introduction
A typical Personal Shopper system is comprised of a family of hardware devices interconnected
through a WLAN radio backbone to the retail establishment’s server(s). The hardware devices are the
PS20 personal shoppers, single slot or three slot cradles, power supplies and cables. A
dispenser
typically refers to a piece of furniture which has mounted to it the cradles, their power supplies, and
cables.
Customers (retail establishments) design their own dispensers to meet their particular floor space and
display requirements. The information in this chapter should help a customer to design a dispenser
and to understand the installation requirements.
IMPORTANT: The MC18 cradles are compatible with the PS20.
Installation of the Single Slot Cradle
Installation of the Single Slot Cradle include the following mounting steps:
• Select the charging mode (see Charging Modes on page 134)
• Mount the Single Slot Cradles on a dispenser wall (see Mounting the Single Slot Cradle on a
Dispenser Wall on page 135)
• Connect the wires to the cables (see Wiring on page 137)
• Set the cradle(s) (see Controlling the Cradle on page 110)
Charging Modes
Single Slot Cradles can be installed in the following charging modes:
• Standard charging
• Fast charging
There are some general charging considerations that must be taken into account when designing a
dispenser and ordering hardware elements of a system:
Standard Charging Mode
• In standard charging mode, no more than 12 cradles can be powered off of one power supply unit
(p/n PWR-BGA12V108W0WW) using “Y” power cable CBL-DC-392A1-02.
• In standard charging mode, the current draw by each docked PS20 can reach a maximum of 1A.
