Zebra PS20 Series User Manual

Wireless
68
Configuring a Secure Wi-Fi Network
To set up a Wi-Fi network:
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the switch to the ON position.
4. The device searches for WLANs in the area and lists them on the screen.
5. Scroll through the list and select the desired WLAN network.
6. Touch the desired network. If the network security is Open, the device automatically connects to the
network. For all other network security a dialog box appears.
Figure 40 WLAN WEP Network Security Dialog Box
Figure 41 WLAN 802.11 EAP Network Security Dialog Box

Zebra PS20 Series Specifications

General

Brand	Zebra
Model	PS20 Series
Category	Handhelds
Language	English
