Applications
98
10.Moving in the direction specified, repeat until all cradles are configured.
If the user abandons programming before the entire wall is completed, the user must start over from the
beginning.
Figure 59 Warning! Restart Configuration Screen
The app detects when it has reached the end of the wall and the Configuration complete dialog displays.
Figure 60 Configuration Complete Dialog
11.Select one of the following:
• QUICK AUDIT - A sample of cradles are validated and the expected data is compared to what is
actually found. Blinking cradles are displayed one after the other at the four corners. The device to be
validated should be placed in the middle slot of the blinking icon.
• FULL AUDIT - All cradles are validated and the expected data is compared to what is actually found.
• RETURN TO HOME PAGE - Displays the CradleSmartConfig screen.
Auditing
Auditing validates that the cradles have been programmed correctly. The expected results should match the
results found.
Quick Audit
To perform a quick audit:
1. The four corner cradles will blink one after another. Place the device in the middle slot of the first blinking
cradle icon.
If the audit was successful and the expected results match the results found, a green screen displays. If the
audit failed and the expected results do not match the results found, a red screen displays.
