Getting Started
26
1.
To charge the batte
ry, connec
t the charging a
c
cessory to the
ap
propriat
e power s
ource.
2.
Insert the PS20 into a crad
le. The PS20 turns on
and begins c
ha
rging.
Figure 5 Single Slot Cradle
Figure 6 Thr
ee Slot Cradle
25
27
