Zebra ZXP 7 series Service Manual

374 ZXP Series 7 Card Printer Service Manual P1036102-007
Cleaning
Dual Cleaning Cartridge
Dual Cleaning Cartridge
Important • It is recommended that you replace the Dual Cleaning Cartridge rollers
every time you install a new ribbon.
Two new card cleaning rollers are included with each ribbon or may be purchased
separately. To order additional rollers, visit www.zebra.com/supplies.
Installation of the Dual Cleaning Cartridge is described in the ZXP Series 7 User’s
Guide (P1036101-003) and is not repeated in detail here.
Manual Feed Cleaning Cassette
Important • It is recommended that you replace the Manual Feed Cleaning Cassette
roller every 5,000 cards.
Manual feed card cleaning rollers must be purchased separately. To order additional
rollers, visit www.zebra.com/supplies.
Installation of the Cleaning Cassette is described in detail in the ZXP Series 7 User’s
Guide (P1036101-003) and is not repeated here.
Cleaning Supplies
Part Number Description
105909G-057 Zebra cleaning swab kit (box of 24)
105950-035 Zebra cleaning pens (box of 12)
105999-701
Zebra Print Station Cleaning Kit: 12 feeder and print path
cleaning cards (enough for 60,000 prints)
105999-704
Zebra Print Station and Laminator Cleaning Kit: 12 feeder, print
path and laminator cleaning cards, 12 cleaning swabs, and 3
adhesive cleaning cards (enough for 60,000 prints)
105912-003 Zebra adhesive cleaning rollers (set of 5)
105999-705 Zebra abrasive printhead polishing card

Zebra ZXP 7 series Specifications

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
