58 ZXP Series 7 Card Printer Service Manual P1036102-007
Replacement Procedures for the Printer
Procedures: Print Cover
Print Cover
Step 1. If not already done, open the Print Cover.
Step 2. With a small Flat-blade screwdriver, carefully remove the left-side E-ring
holding the shaft in place.
Step 3. Slide the shaft out of the print cover brackets.
