Zebra ZXP 7 series Service Manual

P1036102-007 ZXP Series 7 Card Printer Service Manual 63
Replacement Procedures for the Printer
Procedures: Left Side Cover
Left Side Cover
Step 1. From the front of the Printer: With a TORX T10 driver, remove the two screws
holding the Left Cover in place.
Step 2. From the back of the Printer: With a TORX T10 driver, remove the two screws
holding the Left Cover in place.
Step 3. Remove the Left Cover, and set it aside.

Zebra ZXP 7 series Specifications

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
