ZyXEL Communications N4100 User Manual

Chapter 12 Keypad
N4100 User’s Guide
118
5 Use the keypad to create subscriber accounts. Press [ENTER] to generate a new
subscriber account and print the account’s information. The account information
includes a serial number, password and the time the account was created.
Figure 49 Post-Paid Account Printout Example
6 When a subscriber is done using the Internet service, press the following to print a
bill.
*
Serial number
[ENTER]
Figure 50 Post-Paid Account Bill Printout Example
Welcome!
-----------------------------------------
S/N:000001
-----------------------------------------
Hotspot Internet Service
-----------------------------------------
Username:27i28n32
Password:5a789i35
-----------------------------------------
ESSID:ZyXEL
2010/01/22 17:32:58
S/N:000001
Please activate your account before
2010/01/23 05:32:58
-----------------------------------------
Thank you very much !
Welcome!
-----------------------------------------
S/N:000001
-----------------------------------------
Hotspot Internet Service
-----------------------------------------
Username:27i28n32
Password:5a789i35
Usage Time:00:32:01
Total:USD 1.00
-----------------------------------------
2010/01/22 18:25:51
-----------------------------------------
Thank you very much !

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
