ZyXEL Communications N4100 User Manual

Chapter 17 Portal Page, Advertisement Links and Walled Garden
N4100 User’s Guide
156
17.4 The Walled Garden Screen
A subscriber must log in before the N4100 allows the subscriber access to the
Internet. However, with a walled garden, you can define one or more web site
addresses that all subscribers can access without logging in. These can be used for
advertisements for example.
Click ADVANCED > WALLED GARDEN to open this screen.
Figure 79 ADVANCED > WALLED GARDEN
The following table describes the labels in this screen.
17.4.1 Walled Garden Login Example
The following figure shows the subscriber login screen with three walled garden
links. The links are named Walled Garden Link 1 through 3 for demonstration
purposes.
Table 34 ADVANCED > WALLED GARDEN
LABEL DESCRIPTION
Name Enter a descriptive name (up to 80 characters) for the walled garden link
to be displayed in the web browser.
URL or IP
Address
Enter the web site URL (up to 350 ASCII characters) or IP address. For
example, “http://www.zyxel.com”.
Add to List Click this button to append your entry to the list below.
Delete Select the check boxes of entries that you want to remove and click
Apply to remove them.
Delete All Click this button to remove all of the walled garden links.
Apply Click Apply to save your changes back to the N4100.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
