ZyXEL Communications N4100 User Manual

Chapter 28 System Status
N4100 User’s Guide
224
28.8.1 Accessing a LAN Device
Before you can access a LAN device behind the N4100, the following requirements
must be met.
• The LAN device has a web-based management interface and it is enabled.
• You have set up the virtual port mapping to the LAN device server port in the
ADVANCED > LAN DEVICES screen.
•The LAN device status is OK in the SYSTEM STATUS > LAN DEVICES screen.
There are two methods to access the LAN device: directly or through the web
configurator.
1 To access the LAN device through the web configurator, open the SYSTEM
STATUS > LAN DEVICES screen and click the device name. A new Internet
browser should display showing the login screen of the LAN device management
interface.
2 To directly access the LAN device, enter the WAN IP address of your N4100 and
the virtual port number of the LAN device separated by a colon. For example,
enter “http:// 192.168.1.1:60001” where 192.168.1.1 is the WAN IP address of
the N4100. The login screen of the LAN device management interface should
display.
Device Server
Port
This field displays the server port number of the LAN device.
Device MAC
Address
This field displays the MAC address of the LAN device.
Application This field displays the type of application packet that is forwarded to the
LAN device.
Interface This field displays to which interface on the N4100 the LAN device is
connected.
Table 60 SYSTEM STATUS > LAN DEVICES (continued)
LABEL DESCRIPTION

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
