ZyXEL Communications N4100 User Manual

Chapter 3 Tutorials
N4100 User’s Guide
36
Thomas has to configure the wireless network settings on the N4100. Then users
can set up a wireless network using manual configuration (Section 3.2.2 on page
37).
3.2.1 Configuring the N4100 Wireless Network Settings
This example uses the following parameters to set up a wireless network.
Follow the steps below to configure the wireless settings on the N4100.
Note: To see the current SSID, go to the SYSTEM STATUS > SYSTEM or the
System Quick View screen.
1 Open the ADVANCED > WIRELESS screen in the N4100’s web configurator.
Configure the screen using the provided parameters (see page 36).
2 Make sure Enable is selected in the Wireless Connection field.
3 Enter “SSID_Example” as the ESSID and select a channel which is not used by
another AP.
SSID SSID_Example
Security Mode WPA-PSK
Pre-Shared Key DoNotStealMyWirelessNetwork
802.11 Mode IEEE 802.11b/g/n (Mixed)

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
