ZyXEL Communications N4100 User Manual

Chapter 17 Portal Page, Advertisement Links and Walled Garden
N4100 User’s Guide
155
17.3 The Advertisement Screen
You can set the N4100 to display an advertisement web page as the first web page
whenever the subscriber connects to the Internet. Click ADVANCED >
ADVERTISEMENT to open this screen.
Figure 78 ADVANCED > ADVERTISEMENT
The following table describes the labels in this screen.
Table 33 ADVANCED > ADVERTISEMENT
LABEL DESCRIPTION
Advertisement Select Enable to display advertisement web links. otherwise, select
Disable to turn off this feature.
Frequency Select One Time Only to display an advertisement web link in an active
browser window once after a subscriber logs in successfully.
Select Every … Min(s) to display an advertisement web link in an active
browser window once every time period specified (in minutes) after a
subscriber logs in successfully.
Sequence Select Randomly to display the advertisement links in random order,
one at a time.
Select Orderly to display the advertisement links in the order that you
configure them.
URL Link Enter the web site URLs in the fields provided. For example, “http://
www.zyxel.com”. You can use up to 350 ASCII characters.
Apply Click Apply to save your changes back to the N4100.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
