ZyXEL Communications N4100 User Manual

Chapter 3 Tutorials
N4100 User’s Guide
52
3 Players on the Internet then can have access to Thomas’ Doom server.
You can also remotely access the Doom server’s web-based management
interface by entering http://192.168.1.1:60001 or clicking the device name in the
SYSTEM STATUS > LAN DEVICES screen.
4 If you want to manage the Doom server using the N4100’s dynamic domain name
and the virtual port, http://www.domainname.com:60001 for example, see
Section 3.6 on page 49 for how to configure the N4100’s DDNS settings.
3.8 Using SSL Security for Connections between
the N4100 and your Computer
When you connect to N4100 for management or Internet access, you can use SSL
to protect data transfer between the N4100 and the web browser on your
computer.
3.8.1 Activating SSL Security for Management Connections
Follow the steps below to activate the SSL security for management connections
to the web configurator on the N4100.
HTTPS
H
T
T
P
S

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
