ZyXEL Communications N4100 User Manual

Chapter 1 Introduction
N4100 User’s Guide
24
1.5 Restoring Factory Defaults
You can erase the current configuration and restore factory defaults using either
the web configurator or the RESET button at the back of the device.
The web configurator allows you to reset the system but retain subscriber account
information. See Chapter 29 on page 225 for more information.
If you forget your password or cannot access the web configurator, you will need
to use the RESET button to reload the factory-default configuration file. This
means that you will lose all of your custom configuration, including the local
subscriber database, and the administrator password will be reset to “1234”.
1.5.1 Using the Reset Button
1 Make sure the POWER LED is on (not blinking).
2 To set the device back to the factory default settings, use a pointed object to press
the RESET button once or until the PWR LED begins to blink and then release it.
When the PWR LED begins to blink, the defaults have been restored and the
device restarts.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
