ZyXEL Communications N4100 User Manual

Chapter 28 System Status
N4100 User’s Guide
222
28.7 The Session List Screen
Click SYSTEM STATUS > SESSION LIST to open this screen.
Figure 102 SYSTEM STATUS > SESSION LIST
The following table describes the labels in this screen.
Table 59 SYSTEM STATUS > SESSION LIST
LABEL DESCRIPTION
Page Select a page number from the drop-down list box to display the selected
page.
First Click First to go to the first page.
Previous Click Previous to return to the previous page.
Next Click Next to go to the next page.
End Click End to go to the last page.
No. This field displays the index number of an entry.
TCP/UDP This field displays the type of traffic (TCP or UDP).
Client IP This field displays the IP address of the client computer.
Client Port This field displays the port number through which the client computer
transmits the traffic.
Port Fake This field displays the NAT port to and from which the N4100 maps the
session’s traffic.
Remote IP This field displays the IP address of a remote device the client computer
accesses.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
