ZyXEL Communications N4100 User Manual

Chapter 3 Tutorials
N4100 User’s Guide
41
3.3.2 Using a Statement Printer to Create Accounts and Print
Subscriber Statements
Follow the steps below to setup and create subscriber accounts and print
subscriber statements using an external statement printer.
1 Make sure that the printer is connected to the appropriate power and the N4100,
and that there is printing paper in the statement printer. Refer to the printer’s
User’s Guide for details.
2 Press the button on the statement printer. The N4100 generates a dynamic
account and the printer prints the subscriber’s statement. Refer to Figure 9 on
page 40 for a printout example.
Refer to Chapter 13 on page 119 for how to configure the printout page.
3.3.3 Viewing the Account List
Do one of the following to view the account list.
•From the Account Generator Panel screen, (refer to Figure 8 on page 39)
click View Account List.
•From the SYSTEM STATUS sub-menus, click ACCOUNT LIST.
Figure 11 Account List
See Section 28.3 on page 216 for explanation of the account list screen. Refer to
Section 3.4 on page 42 for more information on logging in as a subscriber.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
