ZyXEL Communications N4100 User Manual

Chapter 27 Licensing
N4100 User’s Guide
209
27.3 The Service Screen
Click ADVANCED > LICENSING > Service to open this screen.
Figure 96 ADVANCED > LICENSING > Service
The following table describes the fields in this screen.
Table 53 ADVANCED > LICENSING > Service
LABEL DESCRIPTION
License Status
Service This field displays the service name available on the N4100.
Status This field displays Licensed when the N4100 is registered and a
service is activated.
Registration Type This field displays Standard when the N4100 is registered and a
service is activated.
Count This field displays the current maximum number of wired and wireless
users that may connect to the N4100 at the same time.
License
Activation
License Key Enter your iCard’s PIN number and click Activation to extend the
concurrent user number from 100 (default) to 200.
To upgrade the service, you need to buy an iCard or e-iCard (specific
to the service supported by your N4100) and enter the PIN number to
extend the service.
Service License
Refresh
If you restore the N4100 to the default configuration or upload a
different configuration file after you register, click this button to update
service license information.

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
