ZyXEL Communications N4100 User Manual

Chapter 5 WAN/LAN
N4100 User’s Guide
76
5.3 Technical Reference
The following section contains additional technical information about the N4100
features described in this chapter.
PPTP Server IP
Address
Enter the IP address of your ISP’s PPTP server.
Username Enter the user name exactly as your ISP assigned. If assigned a name in
the form user@domain
where domain identifies a service name, then
enter both components exactly as given.
Password Enter the password associated with the user name above.
PPP MTU
Setting
Enter the MTU (Maximum Transfer Unit) size for PPTP traffic.
TCP MSS
Setting
Enter the MSS (Maximum Segment Size) size.
Connection
ID/Name
Enter your identification name of the PPTP server assigned to you by the
ISP.
Connect on
Demand
Select this option when you don’t want the connection up all the time and
specify an idle timeout in the Max Idle Time field. This is the default
setting with an idle timeout of 10 minutes.
Keep Alive Select this option when you want the Internet connection up all the time
and specify a redial period in the Redial Period field. When
disconnected, the N4100 will attempt to bring up the connection after the
redial period.
Apply Click Apply to save your changes back to the N4100.
Table 8 ADVANCED > WAN/LAN
LABEL DESCRIPTION

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
