ZyXEL Communications N4100 User Manual

Chapter 5 WAN/LAN
N4100 User’s Guide
75
Wan Port
Maximum
Transmission
Unit
Enter the MTU (Maximum Transfer Unit) size for the WAN interface when
you select DHCP Client or Static IP.
WAN Port
Mode
DHCP Client Select this option to set the N4100 to act as a DHCP client on the WAN.
The N4100 obtains TCP/IP information (IP address, DNS server
information, etc.) from a DHCP server. This is the default setting.
Static IP Select this option to set the N4100 to use a static (or fixed) IP address.
IP Address Enter the static IP address in dotted decimal notation.
Subnet
Mask
Enter the subnet mask in dotted decimal notation.
Gateway IP
address
Enter the IP address of the default gateway device. The gateway is a
router or switch on the same network segment as the N4100. The
gateway helps forward packets to their destinations. Leave this field as
0.0.0.0 if you do not know it.
Primary/
Secondary
DNS
Server
Enter the IP addresses of the primary and/or secondary DNS servers.
PPPoE Select this option to activate PPPoE support. Refer to Section 5.3 on
page 76 for more information.
Username Enter the user name exactly as your ISP assigned. If assigned a name in
the form user@domain
where domain identifies a service name, then
enter both components exactly as given.
Password Enter the password associated with the user name above.
PPP MTU
Setting
Enter the MTU (Maximum Transfer Unit) size for PPPoE traffic.
TCP MSS
Setting
Enter the MSS (Maximum Segment Size) size.
Service
Name
Enter the name of your PPPoE service.
Connect on
Demand
Select this option when you don’t want the connection up all the time and
specify an idle timeout in the Max Idle Time field. This is the default
setting with an idle timeout of 10 minutes.
Keep Alive Select this option when you want the Internet connection up all the time
and specify a redial period in the Redial Period field. When
disconnected, the N4100 will attempt to bring up the connection after the
redial period.
PPTP Select this option to activate PPTP support. Refer to Section 5.3 on page
76 for more information.
My IP
Address
Enter the IP address assigned to you.
My Subnet
Mask
Enter the subnet mask assigned to you.
Gateway IP
address
Enter the IP address of the gateway device.
Table 8 ADVANCED > WAN/LAN
LABEL DESCRIPTION

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
