ZyXEL Communications N4100 User Manual

Chapter 20 Syslog
N4100 User’s Guide
169
Server
MAC
Address
Enter the MAC address of the syslog server on the LAN.
Syslog Server
on WAN
Select this check box to specify a syslog server on the WAN.
Server 1 IP
Address
Enter the IP address of the first syslog server on the WAN in dotted
decimal notation.
Server 2 IP
Address
Enter the IP address of the second syslog server on the WAN in dotted
decimal notation.
Send to Email Select Enable to have the N4100 send syslog messages to the e-mail
account that you specify.
Select Disable to not have the N4100 send syslog e-mail messages.
Email Server
IP Address
or Domain
Name
Enter the IP address or domain name of the mail server for the e-mail
addresses specified below. If this field is left blank, the syslog will not be
sent via e-mail.
SMTP Port Enter the port number (25, or between 2500 and 2599) for the mail
server. The default is 25.
E-mail
(SMTP)
server
needs to
check my
account
Select this check box if your SMTP server requires user name and
password authentication before accepting e-mail. Your network
administrator, SMTP server provider or ISP should supply the username
and password.
Username Enter the username for the SMTP server.
Password Enter the password for the SMTP server.
Email From
Name Type a name that you want to be in the “message from” field of the log e-
mail message that the N4100 sends.
Email
Address
Enter your e-mail address. This is the address others use to send e-mail
to Email Address 1/Email Address 2.
Email To
Email
Address
1,2
Enter your first and second e-mail addresses to which the N4100 is to
send the syslog e-mails. If you leave these fields blank, logs will not be
sent via e-mail.
Apply Click Apply to save your changes back to the N4100.
Table 37 ADVANCED > SYSLOG
LABEL DESCRIPTION

ZyXEL Communications N4100 Specifications

General

Number of users	100 user(s)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Indoor range	35 ~ 100 m
Outdoor range	100 ~ 300 m
Connectivity LEDs	Yes
Internal	No
Certification	FCC, CE, C-Tick, NCC, RoHS, WEEE
Security algorithms	802.1x RADIUS
Power requirements	100-240 VAC, 50/60 Hz, 0.5 A
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Weight	565 g
Dimensions (WxDxH)	222 x 146 x 152 mm
