263D SYSTEMS, INC.
Deposition System
A soft coater moves the powder from the feeds onto the build platform.
Build Chute (with build platform)
The parts are printed on a printing plate which is bolted to the build platform. During the print process, the build platform
indexes down to allow subsequent layers of the part to be printed.
Feed Chute (with feed platform)
The feed chute (with feed platform) contains the new metal power. The platform lifts the powder to the correct height to supply
the coater with the right amount of metal powder.
Electrical Connector
Carries all power and signal connections from the process chamber to the build module.
Overow Container
Holds the excess powder until it can be extracted and sieved for re-use.
Overow Chute
Powder deposited in here is lead to the overow containers.
R
S
T
U
V
R
S
T
U
V
W
W
