543D SYSTEMS, INC.
1
2
WARNING: BE CAREFUL WHEN CUTTING THE
RECOATER THIS PRESENTS A CUTTING DANGER.
9. Use a sharp utility knife to cut the recoater in one smooth motion.
10. Leave the recoater housing in the upper part of the coater cutting
tool and cut the ends of the silicone strip where they stick out of
the recoater housing. Cut the corners at a 45° edge. Check if the
silicone strip is smooth with no irregularities. If the recoater is not
smooth, use a new silicon strip and cut it again, repeating Steps
7-9.
11. Re-attach recoater housing to recoater bridge.
12. Move the coater to one of the far sides (1) and move the powder
feed from that side up (2) until the powder is above the module
level by a few millimetres
8. Place the recoater housing in the lower part of the coater cutting tool.
Place the upper part of the coater cutting tool on top.
