ABB AC 800M

Configuring LD 800DN Linking Device Unit Section 4 Configuration
116 9ARD000014-600 A
Baud Rate ENUM kbps 0 3 Editable The baud rate of the DeviceNet
network.
Values are:
125kbps, 250kbps, 500kbps.
Upon modification, Communication
with all DeviceNet devices stops.
Communication resumes after the
connection is re-established.
The modification of the Baud Rate
does not take effect until the device is
power cycled.
Inter Scan
Delay4
INT ms 2 9000 Editable The time delay between successive
scan cycles following the last polled
message.
Upon modification, communication of
linking device with all DeviceNet
devices is stopped momentarily.
The default value is 25ms.
Expected
Packet Rate
INT - 10 32000 Editable The rate at which DeviceNet master
(Linking Device) expects the data to
be received. Applicable only for poll
and strobe type of connections.
The value is unit less and must be
multiplied with 4 to determine the
value in milliseconds
Upon modification, communication of
linking device with all DeviceNet
devices is stopped momentarily.
The default value is 75.
Table 17. Settings for LD 800DN Linking Device Unit (Continued)
Parameter Data Type Unit Min Max
Editable
/Read
Only
Description
