Section 6 Linking Device LD 800DN Faulted Slaves Web Page
9ARD000014-600 A 193
Faulted Slaves Web Page
Figure 75. Faulted Slaves web page
The Faulted Slaves web page, shown in Figure 75, indicates DeviceNet slave nodes
which currently have faults. This indication is only for nodes configured as slaves
under LD 800DN in Control Builder. If a slave is in fault state, the page displays
Faulted status next to the MAC ID of the slave.
A slave node is considered to be in fault, if
the LD 800DN has lost communication
or is unable to establish communication with the slave node. The actual problem can
be determined by viewing the Slave Status web page.
