ABB AC 800M

Section 6 Linking Device LD 800DN Ethernet Network Status LED
9ARD000014-600 A 187
Ethernet Network Status LED
Table 33 shows the Status LED states of an Ethernet Network.
Flashing Red Recoverable fault A fault that can be corrected and does not
require a LD 800DN reset has been
detected.
Red,Green
Alternate
Flashing
Self Test A self test of the module is in progress.
Table 33. Ethernet Network Status LED States
State Summary Description
Off No Power The module has no power or no IP address
assigned.
Solid Green Network OK and communicating There is at least one EtherNet/IP connection.
Flashing Green Network OK There are no active connections.
Solid Red Address conflict The IP address of the module is already in
use by another module.
Flashing Red Connection Time-out The module which is the target in one or more
connection has timed out. This state occurs if
all timed out connections are reestablished or
if the module is reset.
Red,Green
Alternate
Flashing
Self Test A self test of the module is in progress.
Table 32. Ethernet Module Status LED States (Continued)
State Summary Description
