Section 2 Functional Description Status Handling for DeviceNet Slaves
9ARD000014-600 A 37
Status Handling for DeviceNet Slaves
Table 6 shows all DeviceNet slave specific Unit Status bits in ErrorAndWarnings.
Tabl e 6. Errors and Warnings of DeviceNet Device
Bit Value Text Indication Alarm/Event Severity Description
31 0x80000000 Device Not
Found
Warning Alarm High Set when
DeviceNet device
is removed from
network or it is not
accessible.
30 0x40000000 Wrong
Device Type
Warning Alarm High Set if the
electronic Key is
enabled for
DeviceNet device
and its Identity
Information is not
matching with the
device in network.
29 0x20000000 Internal
Config Error
Warning - - Set when the
configuration
requests, to
configure
DeviceNet device,
fails.
28 0x10000000 Connection
Timed Out
Warning Alarm High Set when
Connection with
the DeviceNet
device is not
Timed out
27 0x08000000 Duplicate
MAC Id
Error
Warning Alarm High Set when another
DeviceNet device
found at the same
MAC id.
