Updating LD 800DN Firmware Section 6 Linking Device LD 800DN
176 9ARD000014-600 A
The BridgeWay Configuration window is divided into the following three panes:
• BridgeWay Configuration - Used for displaying the module type and the
status information about the detected LD 800DN module.
• Ethernet Configuration - Used for configuring the Ethernet network
parameters.
• DeviceNet Configuration - Used for configuring the DeviceNet network
parameters. It also displays network interface status.
Updating LD 800DN Firmware
You can perform a Flash Update of the LD 800DN’s firmware, using the BridgeWay
Configuration tool.
Follow these steps for updating the firmware of the linking device:
1. Launch the BridgeWay Configuration tool, by selecting
Start > BridgeWay Configuration. The tool connect to the LD 800DN
module and the BridgeWay Configuration user interface appears
as shown in Figure 64.
2. Click Update from the Flash menu in the menu bar. The Flash Update window
appears as shown in
Figure 65.
For Modular DeviceNet devices, LD establishes connection only to the adapter,
since the connection size is mismatched connection will fail and the whole device
is marked error. If the query interface is in then user can see which specific I/O
module has created this problem as the I/O module which is physically not
available will be marked as Device Not found.
