ABB AC 800M

Tabl e 7. Extended status of DeviceNet Device
Bit Value Text Indication Alarm/Event Severity Description
7 0x00000080 No
Connection
Enabled
Warning Alarm Low Set when no
conn
ections are
enabled for the device
During the update of status information for a modular DeviceNet adapter, the I/O
modules configured under the adapter (the child units) are also updated with the
same status information. The Sub I/O modules that are configured with addresses
1 to 63 under the adapter are updated with status information.
Section 2 Functional Description Status Handling for EtherNet/IP Device
9ARD000014-600 A 39
Status Handling for EtherNet/IP Device
Table 8 shows all EtherNet/IP device specific Unit Status bits in ErrorAndWarnings
and ExtendedStatus.
Tabl e 8. Errors and Warnings of EtherNet/IP device
Bit Value Text Indication Alarm/Event Severity Description
13 0x00002000 Connection
Error
Error Alarm High Set when connection
r
equest from CI873
to this device returns
error.
14 0x00004000 Configuration
Error
Error Alarm High Set when the CI
r
eceives wrong
response when it
wrote configuration
data.
31 0x80000000 Device Not
Fo
und
Error Alarm High Set when the Device
is not present in the
network
