ABB AC 800M

Status Handling for EtherNet/IP Device Section 2 Functional Description
40 9ARD000014-600 A
Refer Appendix B, Troubleshooting CI873 Log Entries for details on
troubleshooting messages displayed in CI873 log files.
30 0x40000000 Wrong
Device Type
Error Alarm High Set when the
different device is
present at the
specified network
address.
29 0x20000000 Internal
Config Error
Warning Alarm Medium Set when the device
r
eturns any of the
general error codes
24 0x01000000 Tag Error Warning Alarm High Set when class3
wr
ite fails
Tabl e 9. Extended Status of EtherNet/IP device
Bit Value Text Indication Alarm/Event Severity Description
7 0x00000080 No
Conn
ection
Enabled
Warning Alarm Low Set when no
connections are
enabled for the device
Table 8. Errors and Warnings of EtherNet/IP device (Continued)
Bit Value Text Indication Alarm/Event Severity Description
