ABB AC 800M

Configuration Error Appendix B Troubleshooting CI873 Log Entries
252 9ARD000014-600 A
Configuration Error
This will be displayed as “Internal Config Error” for the device in Unit Status of the
device. This is indicated as an Warning. The messages displayed in CI873 log files
for the Configuration related errors with the device are shown in the Table 43. The
position of the device in the hardware tree for which the message is printed, is also
printed in the CI873 logs.
Table 43. Configuration Error
Sl
No
Message in CI873 Log Description
Applicability based on
device classification
1 Resources needed for
the object to perform
the requested service
were unavailable
Slave device is loaded heavily
that, it can't handle this
request time being. Try
reducing the slave device load.
EtherNet/IP/DeviceNet
2 Invalid Parameter
value
Value sent in the configuration
request is invalid. Check that
parameter value in EDS file for
the correctness.
EtherNet/IP/DeviceNet
3 The path segment
identifier or the
segment syntax was not
understood by the
processing node
Path used in the configuration
request is not valid. Check the
EDS file for the correctness.
EtherNet/IP
4 The path is
referencing an object
class, instance or
structure element that
is not known or is not
contained in the
processing node
Certain information in EDS file
does not match with the slave
device configuration. Ensure
that the right EDS file for the
device is used. Check the
major and minor version of the
EDS file.
EtherNet/IP/DeviceNet
5 Only part of the
expected data was
transferred
The data sent in the
configuration request is not
complete. Check the EDS file
for the correctness.
EtherNet/IP
