ABB AC 800M

Tabl e 5. Extended status of LD 800DN
Bit Value Text Indication Alarm/Event Severity Description
1 0x00000002 No
Me
ssages
for
Scanner
Warning Alarm Low Set when no CAN
pac
kets received from
DeviceNet network for
more than 10 seconds
2 0x00000004 In Idle
Mo
de
Warning Alarm Low Set when LD goes to
Idle Mode
3 0x00000008 Duplicate
MA
C Id
Check in
progress
Error Alarm Medium Set when LD is checking
f
or Duplicate MAC ID
Check during start up.
4 0x00000010 In Fault
Mo
de
Error Alarm High Set when LD goes to
Fault state
5 0x00000020 Wrong
MacI
D
Error Alarm High Set when the actual
MAC ID of LD 800DN in
the network is not
matching with the MAC
ID configured in CB for
LD 800DN HWUnit
6 0x00000040 Duplicate
MA
C Id
Check
Error
Error Alarm Medium Set when LD 800DN
f
ails to send Duplicate
MAC ID Check request
Status Handling for LD 800DN Section 2 Functional Description
36 9ARD000014-600 A
