The IP address of 200-AENTR can be set in two ways:
• By using the Rotary wheel on the adapter. The limitation when using rotary
wheel is that one can configure IP address of the adapter to only Class C
address range. When the rotary switch is set to a valid number(001-254), the
adapter IP address is192.168.1.xxx (where xxx represents the number set
on the switches). The Adapter will have subnet mask is 255.255.255.0
• The second option is using BOOTP/DHCP server. This has no limitations.
Paths to the BOOTP utility:
For Control Builder Professional:
\Engineering & Development\Control Builder M\Tools\ 200-
A
ENTR\BOOTP-DHCP Server
For Compact Control Builder:
\Tools\ABB\ 200-AENTR\BOOTP-DHCP Server
Section 4 Configuration Configuring S200 Adapter
9ARD000014-600 A 149
