ABB AC 800M

Configuring S200 I/O Modules Section 4 Configuration
164 9ARD000014-600 A
Ctrl Out 0 Bit 00 Start new measurement bit - Channel 0 - when set, start new
measurement on positive edge
Bit 04 Reset Counter, Channel 0 - a positive edge on this bit resets
counter 01
Ctrl Out 1 Bit 01 Start new measurement bit - Channel 1 - when set, start new
measurement on positive edge
Bit 05 Reset Counter, Channel 0 - a positive edge on this bit resets
counter 11
Ctrl Out 2 Bit 02 Start new measurement bit - Channel 2 - when set, start new
measurement on positive edge
Bit 06 Reset Counter, Channel 0 - a positive edge on this bit resets
counter 21
Ctrl Out 3 Bit 03 Start new measurement bit - Channel 3 - when set, start new
measurement on positive edge
Bit 07 Reset Counter, Channel 0 - a positive edge on this bit resets
counter 31
Bit 08-15 Not Used
Table 28. Description of Channels for 200-IP4 (Continued)
Channel Name Definition
