ABB AC 800M

Appendix A Troubleshooting EDS File
228 9ARD000014-600 A
15 <EDS file name>
doesn't have any
connection names.
Import cannot
proceed further!
The IO Info section
is not present in
DeviceNet EDS file
or the Connection
name in IO Info
Section required in
EDS file is missing
or fields available as
not as per CIP
specification
DeviceNet Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields.
16 Invalid device
connections. Please
use correct EDS
file and try again!
The connection
manager section is
not found in EDS
file
EtherNet/IP Import will abort. 
Contact the vendor to
get device EDS files
with all the mandatory
fields.
17 All the IO Modules
importing are not
having connections.
Import cannot
proceed further
This shall come for
IO modules EDS
files if they do not
have connections in
Connection
Manager
EtherNet/IP/
Modular
Import will abort. 
Contact the vendor to
get IO EDS files with
all the Connection
information available.
18 The following IO
Modules does not
have connections
<Rejected Module
name> So the
modules are not
added to the
parsing list
This shall come for
IO modules EDS
files if they do not
have valid
connections in
Connection
Manager.
EtherNet/IP/
Modular
Proceed with the
import by deselecting
the IO modules that
do not have valid
connections. Contact
the vendor to get IO
EDS files with all the
connection
information available
Table 41. Messages - Import of EDS Files (Continued)
Sl
No
Message Reason
Applicability
Based on Device
Classification
Additional
Information and
Workaround
