Section 3 Device Import Wizard Converting an EDS File to a Hardware Unit Type
9ARD000014-600 A 55
.
Figure 11. Multiple file selection dialog
In case of performing a re-import of a Modular I/O EDS file, select the required
adapter file during re-import. A Modular I/O re-import can be done by selecting
the adapter file alone, as the adapter file holds all the references to I/O modules.
If a user attempts importing an adapter consecutively from two different folders
under the same hardware library, then the import is blocked and the following
message is displayed:
An adapter of the similar name from a folder <folder_name>
other than the current folder has been imported. Please
select the adapter from the earlier imported folder or
change the name of the current adapter's eds being imported
and try again
.
