136 Parameters
13
13 Standard AO
Configuration of standard analog outputs.
13.02 AO force selection Selects the analog outputs that will be forced to values
defined by parameters.
The true source signals of the analog outputs can be
overridden for eg. testing purposes. A forced value
parameter is provided for each analog output, and its
value is applied whenever the corresponding bit in this
parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 13.02 and 13.11).
0000h
0000h…FFFFh Forced values selector for analog output AO1. 1 = 1
13.11 AO1 actual value Displays the value of AO1 in mA or V.
This parameter is read-only.
-
0.000…22.000 mA
0.000…11.000 V
Value of AO1. 1 = 1 mA
13.12 AO1 source Selects a signal to be connected to analog output AO1. Output
frequency
Zero None. 0
Motor speed used 01.01 Motor speed used 1
Output frequency 01.06 Output frequency 3
Motor current 01.07 Motor current 4
Motor current % of
motor nom
01.08 Motor current % of motor nom 5
Motor torque 01.10 Motor torque 6
DC voltage 01.11 DC voltage 7
Output power 01.14 Output power 8
Speed ref ramp in 23.01 Speed ref ramp input.10
Speed ref ramp out 23.02 Speed ref ramp output 11
Speed ref used 24.01 Used speed reference 12
Freq ref used 28.02 Frequency ref ramp output 14
Process PID out 40.01 Process PID output actual 16
Temp sensor 1
excitation
The output is used to feed an excitation current to the
temperature sensor 1, see parameter 35.11 Temperature
1 source. See also section Motor thermal protection.
20
Abs motor speed used 01.61 Abs motor speed used 26
Abs motor speed % 01.62 Abs motor speed %
27
Abs output frequency 01.63 Abs output frequency 28
Abs motor torque 01.64 Abs motor torque 30
Abs output power 01.65 Abs output power 31
Abs motor shaft power 01.68 Abs motor shaft power 32
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = Force AO1 to value of parameter 13.13 AO1 forced value.
1…15 Reserved.
ACS180 FW.book Page 136 Tuesday, March 9, 2021 2:25 PM
