ABB ACS180 - Fault Functions

Parameters 205
Torque control Adjustable speed limits are enabled if Torque control
mode (vector motor control) is active.
4
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 5
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 6
DI3 Digital input DI2 (10.02 DI delayed status, bit 2). 7
DI4 Digital input DI2 (10.02 DI delayed status, bit 3). 8
DI5 Digital input DI2 (10.02 DI delayed status, bit 4). 9
Other [bit] Source selection (see Terms and abbreviations). -
30.37 Min speed source Defines the source of a minimum speed limit for the drive
when the source is selected by 30.36 Speed limit
selection.
WARNING! In vector motor control mode only. In
scalar motor control mode, use frequency limits
30.13 and 30.14.
Minimum
speed
Zero None. 0
AI1 scaled 12.12 AI1 scaled value 1
AI2 scaled 12.22 AI2 scaled value 2
Minimum speed 30.11 Minimum speed.11
Other Source selection (see Terms and abbreviations). -
30.38 Max speed source Defines the source of a maximum speed limit for the drive
when the source is selected by 30.36 Speed limit
selection.
WARNING! In vector motor control mode only. In
scalar motor control mode, use frequency limits
30.13 and 30.14.
Maximum
speed
Zero None. 0
AI1 scaled 12.12 AI1 scaled value 1
AI2 scaled 12.22 AI2 scaled value 2
Maximum speed 30.12
Maximum speed.12
Other Source selection (see Terms and abbreviations). -
31
31 Fault functions
Configuration of external events; selection of behavior of
the drive upon fault situations.
31.01 External event 1
source
Defines the source of external event 1.
See also parameter 31.02 External event 1 type.
0 = Trigger event
1 = Normal operation
Inactive
(true)
Active (false) 0. 0
Inactive (true) 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 3
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 4
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 5
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 6
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 7
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
