272 Parameters
58.104 Data I/O 4 Defines the address in the drive which the Modbus master
accesses when it reads from or writes to register address
400004.
For the selections, see parameter 58.101 Data I/O 1.
SW 16bit
58.105 Data I/O 5 Defines the address in the drive which the Modbus master
accesses when it reads from or writes to register address
400005.
For the selections, see parameter 58.101 Data I/O 1.
Act1 16bit
58.106 Data I/O 6 Defines the address in the drive which the Modbus master
accesses when it reads from or writes to register address
400006.
For the selections, see parameter 58.101 Data I/O 1.
Act2 16bit
58.107 Data I/O 7 Parameter selector for Modbus register address 400007.
For the selections, see parameter 58.101 Data I/O 1.
None
58.108 Data I/O 8 Parameter selector for Modbus register address 400008.
For the selections, see parameter 58.101 Data I/O 1.
None
58.109 Data I/O 9 Parameter selector for Modbus register address 400009.
For the selections, see parameter 58.101 Data I/O 1.
None
58.110 Data I/O 10 Parameter selector for Modbus register address 400010.
For the selections, see parameter 58.101 Data I/O 1.
None
58.111 Data I/O 11 Parameter selector for Modbus register address 400011.
For the selections, see parameter 58.101 Data I/O 1.
None
58.112 Data I/O 12 Parameter selector for Modbus register address 400012.
For the selections, see parameter 58.101 Data I/O 1.
None
58.113 Data I/O 13 Parameter selector for Modbus register address 400013.
For the selections, see parameter 58.101 Data I/O 1.
None
58.114 Data I/O 14 Parameter selector for Modbus register address 400014.
For the selections, see parameter 58.101 Data I/O 1.
None
71
71 External PID1
Configuration of external PID.
71.01 External PID act value See parameter 40.01 Process PID output actual.-
71.02 Feedback act value See parameter 40.02 Process PID feedback actual.-
71.03 Setpoint act value See parameter 40.03 Process PID setpoint actual.-
71.04 Deviation act value See parameter 40.04 Process PID deviation actual.-
